Plywood

SWAT Solution to your dream furniture. SWAT Ply is made from selected high density core and face which are treated with Anti termite additives and are further bonded with in-house specially manufactured Phenol Formaldehyde BWP Grade resin, which is Eco-Friendly and non-hazardous to human and animal. Swat Ply comes with double pressed thick face on both sides. Furthur, the finished plywood is subjected to proper chemical treatment with water soluble fixed type preservatives under vacuum pressure to ensure protection against wood destroying organisms and to make the product borer/termite proof and fungi free. SWAT Ply goes through seven step rigorous testing to make it dimensionally stable and anti warp in both dry and humid conditions.

About SWAT Technology:

Extra Thick face
Special anti-termite treatment
High pressure bonding treatment
High temperature bonding
Life time guarantee

SOLID 710 Marine Grade Plywood

Solid Ply Marine Grade is made of well selected pieces of core and face veneer which are bonded with Phenol Formaldehyde BWP Grade resin under high temperature and pressure. Furthur, the finished plywood is subjected to proper chemical treatment with water soluble fixed type preservatives under vacuum pressure to ensure protection against wood destroying organisms and to make the product insect, borer, termite and fungi free. This specific stress relieving treatment is also given to check anti- warp properties of plywood. The same makes it dimensionally stable in both excessive wet and dry condition throughout its life.

Technical Specifications IS 710
Test	ISI Requirement	Results
Moisture content	5% - 15%	12%
Glue shear strength in dry condition	a. Individual Min. 1100 Newton, b. Average 1350 Newton.	a. 1550 Newton b. 1700 Newton
Glue shear strength	a. Individual Min. 800 Newton, b. Average 1000 Newton.	a. 1300 Newton b. 1225 Newton
Glue Shear Strength in mycological test	a. Individual Min. 800 Newton, b. Average 1000 Newton.	a. 960 Newton b. 1200 Newton
Tensile Strength: a. Parallel to grain direction b. Right angle to grain direction c. Sum of both directions	a. Min. 420 Kgf./cm2 b. Min. 250 Kgf./cm2 c. Min. 845 Kgf./cm2	a. 540 Kgf./cm2 b. 370 Kgf./cm2 c. 910 Kgf./cm2

SOLID 303 MR Grade Plywood

Solid MR Grade Plywood is made of high quality inner core and outer surface and is bonded by MUF resin. The plywood has strong screw holding capacity and is extra resistant to Moisture, Water, Borer and Outdoor and Indoor conditions. It is ideal for use in Borer and Moisture prone areas. Solid MR Grade Plywood is ideal for furniture use. It is made keeping Indian conditions in mind. {Tech specs separately in excel}

Grade	MOE{N/mm2}		MOR{N/mm2}
Grade	Average	Min. Ind.	Average	Min. Ind.
BWR Grade a. Along {direction parallel to the grain direction of the face veneer} b. Across {direction perpendicular to the grain direction of the face veneer}	a. 5000 b. 2500	a. 4500 b. 2200	a. 40 b. 20	a. 36 b. 18
MR Grade a. Along {direction parallel to the grain direction of the face veneer} b. Across {direction perpendicular to the grain direction of the face veneer}	a. 4000 b. 2000	a. 3600 b. 1800	a. 30 b. 15	a. 27 b. 13
